Known Issues

Custom STIX Extensions

STIG has been modified using custom STIX extensions. These extensions bring more functionality to STIG but may cause exported STIX bundles to fail the Oasis STIX validator.

Infrastructure Object infrastructure-type-ov

STIG was modified to accept the following additional infrastructure-type-ov vocab entries:

  • firewall – Device that inspects network traffic, and restricts is based upon defined policies

  • workstation – General machine used for work by an organization that needs protection.

  • infrastructure – routers/switches

  • control-system – such as IoT, HMI, RTU, PLC or other ICS devices.

These modifications allows user to represent Defender Infrastructure in STIX.

Unhandled Promise Rejection

_images/unhandled-promise-rejection.jpg

An Unhandled Promise Rejection error can occur after running the STIG installation or executable if Neo4j is not installed and running. To clear this error, make sure Neo4j is installed/running and connected to STIG (Edit -> Configure menu).

Database Issues

  • A commit to the database does not check for duplicate objects.

  • The build_db.py script has connection issues when the database is on a remote server. The script works fine with a locally hosted database.

  • STIG needs to be connected to a database before manupulating a graph. If the user connects to a database after working on a STIG graph, the graph will be cleared when the database connects.

Layout Issues

  • There can be issues with the Cose-Bilkent layout not settling properly - can cause subsequent layout changes to not work correctly.

  • Switching layouts from Spread to Grid rapidly (back and forth) can cause subsequent layouts to not render properly.

Other Issues

  • Missing functionality with portions of the File menu.


  • All other issues are listed on the STIG github site.
